Product Details:
Place of Origin: China
Brand Name: trusTec
Certification: UL Approval E529388,CE approval
Model Number: ZTD94-90-8A
Payment & Shipping Terms:
Minimum Order Quantity: 200pcs
Price: Negotiable (EXW/FOB/CNF/CIF)
Packaging Details: Standard carton packing, foam board inside for protection.
Delivery Time: 15 work days after order confirmation.
Payment Terms: T/T, L/C
Supply Ability: 100,000 pcs per month
Contact Now
Detailed Product Description
Hall Sensor: Sensorless Product Name: BLDC Fan Motor
Application: Ventilation Output Power: 90W
Pole: 8 Voltage: 220V
Frequency: 50/60Hz Speed: 300-1500RPM
ODM Solutions: Customized AC And EC Motors ODM Solutions: Customized AC And EC Motors
ODM Solutions: ODM Solutions: Customized AC And EC Motors
High Light:

cross flow blower fan


dc cross flow fan


1500RPM BLDC Fan Motor

BLDC Fan Motor

Technical Parameters:

Input Power
Output Power
ZTD/ZTS-25-8 220 50 38 0.35 25 1150 0.21
ZTD/ZTS-35-8 220 50 50 0.45 35 1200 0.28
ZTD/ZTS-50-8 220 50 71 0.6 50 1200 0.4
ZTD/ZTS-70-8 220 50 93 0.75 70 1250 0.53
ZTD/ZTS-90-8 220 50 112 0.9 90 1250 0.69
ZTD/ZTS-120-8 220 50 150 1.2 120 1300 0.88
ZTD/ZTS-150-8 220 50 183 1.43 150 1300 1.1
ZTD/ZTS-200-10 220 50 235 1.81 200 1400 1.36
ZTD/ZTS-250-10 220 50 290 2.21 250 1400 1.71
ZTD/ZTS-500-10 220 50 568 4.23 500 1400 3.41


Listed are representitive models, performance parameters dimensions can be customized according to request.


1. Ttrustec EC(BLDC) motor can be AC 110V/220V 50Hz/60Hz or DC 24V/48V/310V input.


2. Ttrustec EC(BLDC) motor is up to 85% efficiency, power factor 0.5~0.6 .


3. Ttrustec EC(BLDC) motor can be 0-10VDC/PWM variable speed, multi speeds or single speed.


4. Ttrustec EC(BLDC) motor uses sensorless vector field-oriented control(FOC), lower material cost and smaller failure rate because of no hall sensor, higher efficiency, lower noise, smoother performance curves.

500W 80% Efficiency EC BLDC Fan Motor, Volute Housed Centrifugal Blower Fan Motor


HVAC/R fields: air conditioners, centrifugal fans, duct air conditioning unit, treating plant, variable air volume system, etc.


Product Features:

Use low noise high quality ball bearing.

Nickel plating for shaft, electrophoretic coating for enclosure.

IP00~IP54, INS. Class B/F available.
