TRUSTEC MOTOR YOUR TRUSTED FACTORY
Sales & Support:
 |
| Place of Origin: | Changzhou, China |
| Brand Name: | trusTec |
| Certification: | CE |
| Model Number: | TZD-125-10A-TVM |
| Minimum Order Quantity: | 200 pcs |
|---|---|
| Price: | Negotiable (FOB/CNF/CIF) |
| Packaging Details: | Standard carton packing, foam board inside for protection. |
| Delivery Time: | 15 days fresh products after order confirmation. |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100,000 pcs per month |
| Product: | Electroncally Commutated Motor (ECM) | Supply Voltage: | 220V |
|---|---|---|---|
| Enclosure Type: | TEAO(Totally Enclosed Air Over) | Supply Frequency: | 50/60HZ |
| Thermal Overload: | Equipped With An Automatic Thermal Overload | Current: | 1.65A |
| Phase: | Single Phase | Output Power: | 125W |
| Mounting: | Stud Mounting All Angel | Speed: | 900RPM |
| Bearings: | Ball Bearing | Poles: | 10P |
| Mounting Orientation: | All Angle | Shaft Length: | 3.04" / 78mm |
| Insulation Class: | Class B | Frame Size: | 120mm |
| Max. Ambient Temperature: | 40℃/104℉ | Shaft Diameter: | 1/2" / 12.7mm |
| Rotation: | CCW(SE) | Flat Length: | 1.99" / 50mm |
| Speed Control: | 0-10V VSP | Lead Length: | 11.8" / 300mm |
| Other: | FG And 10VDC | ||
| Highlight: | 125W BLDC Motor,900RPM BLDC Motor,220V BLDC Motor |
||
