TRUSTEC MOTOR YOUR TRUSTED FACTORY
Sales & Support:
 |
| Place of Origin: | Changzhou, China |
| Brand Name: | trusTec |
| Certification: | CE |
| Model Number: | TRZ95-90-8 |
| Minimum Order Quantity: | 200 pcs |
|---|---|
| Price: | Negotiable (FOB/CNF/CIF) |
| Packaging Details: | Standard carton packing, foam board inside for protection. |
| Delivery Time: | 15 days fresh products after order confirmation. |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100,000 pcs per month |
| Product: | Electroncally Commutated Motor (ECM) | Frame Size: | 95mm |
|---|---|---|---|
| Motor Type: | Direct Drive Blower | Supply Voltage: | 220V |
| Enclosure Type: | TEAO(Totally Enclosed Air Over) | Supply Frequency: | 50HZ |
| Thermal Overload: | Equipped With An Automatic Thermal Overload | Current: | 0.85A |
| Phase: | Single Phase | Output Power: | 90W |
| Mounting: | All Angel | Speed: | 2800RPM |
| Bearings: | Ball Bearing | Poles: | 8P |
| Mounting Orientation: | Stud Mounting All Angel | Shaft Diameter: | 0.26" / 6.5mm |
| Insulation Class: | Class B | Shaft Length: | 1.49"/38mm |
| Rotation: | CW(SE) | Lead Length: | 7.87"/200mm |
| Max. Ambient Temperature: | 40℃/104℉ | Speed Control: | 0-10V Speed Control |
| Highlight: | 2800RPM ECM Motor For Fan,90W ECM Motor For Fan,220V ECM Motor For Fan |
||
