TRUSTEC MOTOR YOUR TRUSTED FACTORY
Sales & Support:
 |
| Place of Origin: | Changzhou, China |
| Brand Name: | trusTec |
| Certification: | CE |
| Model Number: | TZS-375-10A56-ACR |
| Minimum Order Quantity: | 200 pcs |
|---|---|
| Price: | Negotiable (FOB/CNF/CIF) |
| Packaging Details: | Standard carton packing, foam board inside for protection. |
| Delivery Time: | 15 days fresh products after order confirmation. |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100,000 pcs per month |
| Product: | Brushless DC Motor | Supply Voltage: | 208-230V |
|---|---|---|---|
| Enclosure Type: | TEAO(Totally Enclosed Air Over) | Supply Frequency: | 50/60HZ |
| Thermal Overload: | Equipped With An Automatic Thermal Overload | Current: | 2.0A |
| Phase: | Single Phase | Output Power: | 1/2Hp |
| Mounting: | Bracket | Speed: | 300-1050RPM |
| Bearings: | Ball Bearing | Poles: | 10P |
| Mounting Orientation: | All Angle | Frame Size: | 144mm |
| Insulation Class: | Class B | Shaft Length: | 9.05"/230mm |
| Control Mode: | PWM | Shaft Diameter: | 1/2" / 12.7mm |
| Rotation: | CCW(LE) | Speed Feedback: | 36Pluse/revolution |
| Max. Ambient Temperature: | 40℃/104℉ | Lead Length: | 19.6"/500mm |
| Highlight: | BLDC Fan Coil Unit Motor,1/2HP BLDC Fan Coil Unit Motor,1050RPM BLDC Fan Coil Unit Motor |
||
Contact Person: Selena Chai
Tel: +86-13961191626
Fax: 86-519-85109398
