TRUSTEC MOTOR YOUR TRUSTED FACTORY
Sales & Support:
 |
| Place of Origin: | Changzhou, China |
| Brand Name: | trusTec |
| Certification: | CE |
| Model Number: | YDK-190-6A-BRS |
| Minimum Order Quantity: | 200 pcs |
|---|---|
| Price: | Negotiable (FOB/CNF/CIF) |
| Packaging Details: | Standard carton packing, foam board inside for protection. |
| Delivery Time: | 15 days fresh products after order confirmation. |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100,000 pcs per month |
| Product: | Condenser Fan Motor | Frame Size: | 139mm |
|---|---|---|---|
| Motor Type: | Permanent Split Capacitor | Supply Voltage: | 220-240V |
| Enclosure Type: | TEAO(Totally Enclosed Air Over) | Supply Frequency: | 50Hz |
| Thermal Overload: | Equipped With An Automatic Thermal Overload | Current: | 1.72A |
| Phase: | Single Phase | Output HP: | 190W |
| Shaft Flats: | One Flat | Rated Speed: | 825RPM |
| Mounting: | Stud Mounting All Angel | Shaft Diameter: | 0.5" /12.7mm |
| Insulation Class: | Class B | Shaft Length: | 3.82" /97mm |
| Bearings: | Ball Bearing | Capacitor: | 5uF/450V |
| Rotation: | CCW-SE | Max. Ambient Temperature: | 40℃/104℉ |
| Flat Length: | 2.75" / 70mm | Lead Length: | 43.3" / 1100mm |
| Highlight: | 190W AC Fan Motor,825RPM AC Fan Motor |
||
