| Place of Origin: | Changzhou, China |
| Brand Name: | trusTec |
| Certification: | CE |
| Model Number: | YL90S-4-VPL |
| Minimum Order Quantity: | 200 pcs |
|---|---|
| Price: | Negotiable (FOB/CNF/CIF) |
| Packaging Details: | Standard carton packing, foam board inside for protection. |
| Delivery Time: | 15 days fresh products after order confirmation. |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100,000 pcs per month |
| Product: | Double Value Capacitor Asynchronous Motor | Center Height Of Frame: | 90mm |
|---|---|---|---|
| Motor Type: | Induction Motor | Supply Voltage: | 220V |
| Enclosure Type: | TEAO(Totally Enclosed Air Over) | Supply Frequency: | 50Hz |
| Thermal Overload: | Equipped With An Automatic Thermal Overload | Current: | 7.3A |
| Phase: | Single Phase | Output HP: | 1.1KW |
| Motor Housing: | Aluminum Shell | Rated Speed: | 1400RPM |
| Bearings: | Ball Bearing | Pole: | 4P |
| Motor Winding: | 100% Copper Winding | Mounting Type: | B3 |
| Insulation Class: | Class F | ||
| Highlight: | 50/60HZ Blower Fan Motor,230/115V Blower Fan Motor,5uF/370V Blower Fan Motor |
||
| Model | Voltage(V) | Frequency(Hz) | Power(KW) | Speed(RPM) | Current(A) |
|---|---|---|---|---|---|
| YL712-4 | 220 | 50 | 0.37 | 1400 | 2.8 |
| YL801-4 | 220 | 50 | 0.55 | 1400 | 4 |
| YL802-4 | 220 | 50 | 0.75 | 1400 | 5.1 |
| YL90S-4 | 220 | 50 | 1.1 | 1400 | 7.3 |
| YL100L1-4 | 220 | 50 | 2.2 | 1400 | 13.9 |
