| Place of Origin: | Changzhou, China |
| Brand Name: | trusTec |
| Certification: | CE |
| Model Number: | YDK-95-6A6(KVF3E507A) |
| Minimum Order Quantity: | 200 pcs |
|---|---|
| Price: | Negotiable (FOB/CNF/CIF) |
| Packaging Details: | Standard carton packing, foam board inside for protection. |
| Delivery Time: | 15 days fresh products after order confirmation. |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100,000 pcs per month |
| Product: | Outdoor Fan Motor | Frame: | Nema 42 |
|---|---|---|---|
| Motor Type: | Capacitor Run Motor | Supply Volatge: | 220V |
| Enclosure Type: | TEAO(Totally Enclosed Air Over) | Supply Frequency: | 50Hz |
| Thermal Overload: | Equipped With An Automatic Thermal Overload | Current: | 0.95A |
| Phase: | Single Phase | Output HP: | 1/8HP |
| Shaft Flats: | One Flat | Rated Speed: | 900RPM |
| Mounting: | MTG. Bracket (Horizontal Direction) | Capacitor: | 6.0uF/450V |
| Insulation Class: | Class B | Shaft Length: | 3.5" |
| Bearings: | Ball Bearing | Shaft Diameter: | 1/2" |
| Max. Ambient Temperature: | 40℃/104℉ | Rotation: | CW |
| Replacement Motor: | Kulthorn KVF3E507A | ||
| Highlight: | Nema 42 Outdoor Fan Motor,1/8HP Outdoor Fan Motor,900RPM Outdoor Fan Motor |
||
