Place of Origin: | Changzhou, China |
Brand Name: | trusTec |
Certification: | CE、High-tech Enterprise Certificate、ISO9000 Certificate 2023 |
Model Number: | YDK-95-6A5 |
Minimum Order Quantity: | 200 pcs |
---|---|
Price: | Negotiable (FOB/CNF/CIF) |
Packaging Details: | Standard carton packing, foam board inside for protection. |
Delivery Time: | 15 days fresh products after order confirmation. |
Payment Terms: | T/T, L/C |
Supply Ability: | 100,000 pcs per month |
High Light: | Asynchronous Outdoor Fan Motor,Air Ventilation Outdoor Fan Motor,Screw Mounting AC Motor 95W |
---|
Product Name | Outdoor Fan Motor | Voltage | 220V-240V |
---|---|---|---|
Frequency | 50 Hz | Output Power | 95W |
Pole | 6P | AMPS | 1.05A |
Speed | 900RPM | Capacitor | 6μF/450V |
Insulation Class | Class B |
Power Factor |
0.9 |
Other protection | THERMALLY PROTECTED |
Key Parameters
Model |
Power /W |
Frequency /Hz |
Speed /RPM |
Rated Current /A |
Voltage /V |
YDK-95-6A5 | 95 | 50 | 900 | 1.05 | 220-240 |
Ps:all dimension can be customized according to customer requirement.
Product Features
1. Well-formed, small size, light-weight, motor body length and weight are both smaller than other metal shell motors about 25%.
2. Small vibration, low noise, stable operation; under power frequency power supply, resin packed motor sound pressure intensity is 7 dB lower than steel shell motors, under variable-frequency power supply it is 9 dB lower.
3. Energy-saving high efficiency, with 70% efficiency-conversion, 10% energy-saving than general motors.
Product Applications
1. Air conditioner indoor / outdoor unit.
2. Air Purifiers, Air refresher.
3. Range hood, sewer grinder, dehumidifier, medical equipment, special blender etc.
Main Advantages
1. Our mature management is born from motor technicians.
2. ODM and OEM offer.
3. UL, ROHS, CE,CCC, certificate and strict quality control.
4. We have had more than 10 years export experience, especially to Mid-east and South America.
5. Own a competent and honest sales team, always efficient to all your requirements.
6.We have been in this industry for over 17 years now.
FAQ
Q1- What is the warranty of the motors?
The warranty is 36 months on the production date, under the warranty we will afford the shipping cost to send the replacement.
Q2- What is the application of the motors?
All the motors are widely used in HVC&R line.
Q3- Can you design the motor according to the different request?
Yes, we can offer the ODM.
Q4- Do you have distributors overseas?
Yes. We have distributors in USA, Holland, Spain, Turkey, Sudan, UAE, KSA...
Q5- What is the most important advantage for the export?
Besides the competitive price with the good quality, the critical point is the quick response, the efficient export team and the fast delivery time.
Q6- How to get the accurate offer?
The precise price will be quoted after checking the specification and mounting dimension of the motor.
